DP241-6-120A40
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 30VA CHAS MOUNT
PDF
/
Inventory: 8010
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 42.93mm
Length 82.55mm
Height Seated (Max) 42.93mm
Technical
VA Rating 30 VA
Secondary Winding(s) Single
Voltage - Secondary (Full Load) 120V
Center Tap Yes
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 120V
Power - Max 30VA
Max Output Current 250mA
Voltage - Isolation 2500Vrms
Physical Dimension L82.55XB42.93XH49.28 (mm)
Approval Agency UL; CSA
Termination Style Solder, Quick Connect
Max Power Dissipation 30W
Power Rating 30W
Additional Feature HIGH ISOLATION
Type Laminated Core
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 82.55mm Lx49.28mm W
Series Chassis-Tran
Published 2009
Packaging Bulk
Physical
Weight 1.1lbs 499g
Mounting Type Chassis Mount
Mount Chassis Mount
