DP241-4-28A16
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 6VA CHAS MOUNT
PDF
/
Inventory: 5643
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 31.75mm
Length 60.45mm
Height Seated (Max) 37.75mm
Technical
VA Rating 6 VA
Secondary Winding(s) Single
Voltage - Secondary (Full Load) 28V
Center Tap Yes
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 28V
Power - Max 6VA
Max Output Current 200mA
Voltage - Isolation 2500Vrms
Physical Dimension L60.45XB31.75XH35.05 (mm)
Approval Agency UL; CSA
Termination Style Solder, Quick Connect
Max Power Dissipation 6W
Power Rating 6W
Additional Feature HIGH ISOLATION
Type Laminated Core
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 60.45mm Lx35.05mm W
Series Chassis-Tran
Published 2009
Packaging Bulk
Physical
Weight 0.44lb 199.58g
Mounting Type Chassis Mount
Mount Chassis Mount
