BV048-5386.0
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 10VA THRU HOLE
PDF
/
Inventory: 5465
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 42.5mm
Length 60mm
Height Seated (Max) 34.60mm
Height 1.36mm
Technical
Secondary Winding(s) Single
Voltage - Secondary (Full Load) 24V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 230V
Power - Max 10VA
Current - Output (Max) 416mA
Max Output Current 416mA
Termination Style PC Pin
Max Power Dissipation 10W
Type Laminated Core
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 60.00mm Lx42.50mm W
Physical
Weight 0.133lb 60.33g
Mounting Type Through Hole
Mount Through Hole
