RoHS
/
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 10VA THRU HOLE
PDF
/
Inventory: 9655
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Weight 0.133lb 60.33g

Technical

Size / Dimension 50.50mm Lx42.50mm W
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Type Laminated Core
Max Operating Temperature 40°C
Min Operating Temperature 0°C
Power Rating 10W
Max Power Dissipation 10W
Termination Style PC Pin
Max Output Current 834mA
Current - Output (Max) 834mA
Power - Max 10VA
Voltage - Primary 230V
Primary Winding(s) Single
Center Tap No
Voltage - Secondary (Full Load) 12V
Secondary Winding(s) Single

Dimensions

Height 34.5mm
Height Seated (Max) 34.50mm
Length 50.5mm
Width 42.5mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
