BV030-7331.0
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 2.3VA THRU HOLE
PDF
/
Inventory: 3682
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 27.5mm
Length 32.5mm
Height Seated (Max) 29.00mm
Height 1.14mm
Technical
Secondary Winding(s) Single
Voltage - Secondary (Full Load) 15V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Power - Max 2.3VA
Current - Output (Max) 154mA
Max Output Current 154mA
Termination Style PC Pin
Max Power Dissipation 2.3W
Type Laminated Core
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 32.50mm Lx27.50mm W
Physical
Weight 0.133lb 60.33g
Mounting Type Through Hole
Mount Through Hole
Alternative Model
