A41-25-20A19 image
Favorite
A41-25-20A19 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description Power Transformer 4000Vrms 25VA 8Term. Quick Connect/Solder Lug Flange Mount
PDF
/
Inventory: 1554
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Width 47.62mm
Length 71.42mm
Height Seated (Max) 47.63mm
Height 58.72mm

Technical

VA Rating 25 VA
Number of Secondary Winding 2
Output Voltage 2 10V
Voltage - Secondary (Full Load) Parallel 10V Series 20V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Isolation Voltage 4000V
Output Voltage 1 10V
Power - Max 25VA
Current - Output (Max) Parallel 2.5A Series 1.25A
Max Output Current 1.25A
Approval Agency UL; CSA; TUV
Termination Style Solder, Quick Connect
Depth 58.7mm
Max Power Dissipation 25W
Power Rating 25W
Additional Feature PARALLEL CONNECTED
Type Laminated Core
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 71.42mm Lx58.72mm W
Series International High Power
Published 2007

Physical

Weight 1.3lbs 589.7g
Number of Pins 8
Mounting Type Chassis Mount
Mount Chassis Mount, Flanges
