A41-130-12A10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 130VA CHAS MOUNT
PDF
/
Inventory: 2463
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount, Flanges
Mounting Type Chassis Mount
Weight 4.1lbs 1.9kg
Technical
Packaging Bulk
Published 2007
Series International High Power
Size / Dimension 71.42mm Lx85.85mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type Laminated Core
Additional Feature PARALLEL CONNECTED
Power Rating 130W
Max Power Dissipation 130W
Termination Style Solder, Quick Connect
Approval Agency UL; CSA; TUV
Physical Dimension L71.42XB73.02XH85.72 (mm)
Max Output Current 10.3A
Current - Output (Max) Parallel 20.6A Series 10.3A
Power - Max 130VA
Output Voltage 1 6.3V
Isolation Voltage 4000V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Output Voltage 2 6.3V
Number of Secondary Winding 2
VA Rating 130 VA
Dimensions
Height 85.85mm
Height Seated (Max) 73.02mm
Length 71.42mm
Width 73.02mm
Compliance
RoHS Status RoHS Compliant
