241-7-120A50 image
Favorite
241-7-120A50 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 56VA CHAS MOUNT
PDF
/
Inventory: 2467
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Published 2009
Series Chassis-Tran
Size / Dimension 93.73mm Lx57.15mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
ECCN Code EAR99
Type Laminated Core
Additional Feature HIGH ISOLATION
Power Rating 56W
Max Power Dissipation 56W
Termination Style Solder, Quick Connect
Approval Agency UL; CSA
Physical Dimension L93.73XB45.97XH57.15 (mm)
Voltage - Isolation 2500Vrms
Max Output Current 500mA
Power - Max 56VA
Output Voltage 1 120V
Voltage - Primary 115V
Primary Winding(s) Single
Center Tap Yes
Voltage - Secondary (Full Load) 120V
Number of Secondary Winding 1
Packaging Bulk
VA Rating 56 VA

Physical

Weight 1.7lbs 771.1g
Mounting Type Chassis Mount
Mount Chassis Mount

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 45.97mm
Length 93.73mm
Height Seated (Max) 45.97mm
