14A-56-16B18
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 56VA THRU HOLE
PDF
/
Inventory: 6402
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 1.7lbs 771.1g
Technical
Packaging Bulk
Published 2009
Series International PC Plug-In
Size / Dimension 76.20mm Lx63.50mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Additional Feature PARALLEL CONNECTED
Power Rating 56W
Max Power Dissipation 56W
Termination Style PC Pin
Approval Agency UL; CSA; TUV
Physical Dimension L76.2XB63.5XH46.02 (mm)
Max Output Current 3.5A
Current - Output (Max) Parallel 7A Series 3.5A
Power - Max 56VA
Output Voltage 1 8V
Isolation Voltage 4000V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 8V Series 16V
Output Voltage 2 8V
Secondary Winding(s) Single, Multiple Taps
VA Rating 56 VA
Dimensions
Height 46.0248mm
Height Seated (Max) 46.02mm
Length 76.2mm
Width 63.5mm
Compliance
RoHS Status RoHS Compliant
