14A-30-28B35
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 30VA THRU HOLE
PDF
/
Inventory: 1914
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 1.2lbs 544.3g
Technical
Packaging Bulk
Published 2009
Series International PC Plug-In
Size / Dimension 66.68mm Lx55.55mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
HTS Code 8504.31.40.35
Power Rating 30W
Max Power Dissipation 30W
Termination Style PC Pin
Approval Agency UL; CSA; TUV
Physical Dimension 66.675mm X 55.5498mm X 39.6748mm
Max Output Current 1.06A
Current - Output (Max) Parallel 2.12A Series 1.06A
Power - Max 30VA
Output Voltage 1 14V
Isolation Voltage 4000V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 14V Series 28V
Output Voltage 2 14V
Secondary Winding(s) Single, Multiple Taps
VA Rating 30 VA
Dimensions
Height 39.6748mm
Height Seated (Max) 39.67mm
Length 66.675mm
Width 55.5498mm
Compliance
RoHS Status RoHS Compliant
