14A-30-12B11
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformer 4000Vrms 30VA 8Term. PC Pin Thru-Hole
PDF
/
Inventory: 990
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 55.5498mm
Length 66.68mm
Height Seated (Max) 39.67mm
Height 39.6748mm
Technical
Secondary Winding(s) Single, Multiple Taps
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Lead/Base Style PC Pin
Power - Max 30VA
Element Configuration Dual
Current - Output (Max) Parallel 4.8A Series 2.4A
Max Output Current 2.4A
Termination Style PC Pin
Depth 55.54mm
Max Power Dissipation 30W
Power Rating 30W
Type Laminated Core
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 66.68mm Lx55.55mm W
Series International PC Plug-In
Published 2009
Packaging Bulk
Physical
Weight 1.2lbs 544.3g
Number of Pins 8
Mounting Type Through Hole
Mount Through Hole
