14A-20-20B22 image
Favorite
14A-20-20B22 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 20VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $14
Unit Price: USD $14.0008
≥1 USD $14.0008
≥10 USD $12.9096
Inventory: 66
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Length 57.15mm
Height Seated (Max) 41.28mm
Height 41.275mm

Technical

VA Rating 20 VA
Secondary Winding(s) Single, Multiple Taps
Output Voltage 2 10V
Voltage - Secondary (Full Load) Parallel 10V Series 20V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Isolation Voltage 4000V
Output Voltage 1 10V
Lead/Base Style PC Pin
Power - Max 20VA
Current - Output (Max) Parallel 2A Series 1A
Max Output Current 1A
Physical Dimension L57.15XB47.62XH41.27 (mm)
Approval Agency UL; CSA; TUV
Termination Style PC Pin
Depth 47.62mm
Max Power Dissipation 20W
Power Rating 20W
Additional Feature PARALLEL CONNECTED
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 57.15mm Lx47.63mm W
Series International PC Plug-In
Published 2009
Packaging Bulk

Physical

Weight 0.9lb 408.23g
Number of Pins 8
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 10 Weeks
