14A-20-16B16 image
Favorite
14A-20-16B16 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description Power Transformer 4000Vrms 20VA 8Term. PC Pin Thru-Hole
PDF
/
Inventory: 7819
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Number of Pins 8
Weight 0.9lb 408.23g

Technical

Packaging Bulk
Published 2009
Series International PC Plug-In
Size / Dimension 57.15mm Lx47.63mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Type Laminated Core
Power Rating 20W
Max Power Dissipation 20W
Depth 47.62mm
Termination Style PC Pin
Max Output Current 1.25A
Current - Output (Max) Parallel 2.5A Series 1.25A
Element Configuration Dual
Power - Max 20VA
Lead/Base Style PC Pin
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 8V Series 16V
Secondary Winding(s) Single, Multiple Taps

Dimensions

Height 41.275mm
Height Seated (Max) 41.28mm
Length 57.15mm
Width 47.63mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
