14A-2.5-10B1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 2.5VA THRU HOLE
PDF
/
Inventory: 9741
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 33.32mm
Length 41.27mm
Height Seated (Max) 28.58mm
Height 28.575mm
Technical
VA Rating 2.5 VA
Secondary Winding(s) Single, Multiple Taps
Output Voltage 2 5V
Voltage - Secondary (Full Load) Parallel 5V Series 10V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Isolation Voltage 4000V
Output Voltage 1 5V
Lead/Base Style PC Pin
Power - Max 2.5VA
Current - Output (Max) Parallel 500mA Series 250mA
Max Output Current 250mA
Physical Dimension L41.27XB33.32XH28.57 (mm)
Approval Agency UL; CSA; TUV
Termination Style PC Pin
Shielding Unshielded
Max Power Dissipation 2.5W
Power Rating 2.5W
Additional Feature PARALLEL CONNECTED
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 41.28mm Lx33.32mm W
Series International PC Plug-In
Physical
Weight 0.25lb 113.4g
Mounting Type Through Hole
Mount Through Hole
