RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers Class2, Energy Limit 347V, 1.67A, 40VA
PDF
/
Buying Options
Total Price: USD $17.37
Unit Price: USD $17.372015
≥1 USD $17.372015
≥10 USD $16.388689
≥100 USD $15.461034
≥500 USD $14.585879
≥1000 USD $13.760264
Inventory: 9243
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 1.5lbs 680.4g
Technical
Packaging Bulk
Published 2000
Series BE
Size / Dimension 59.18mm Lx66.04mm W
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Quick Connect
ECCN Code EAR99
Type Laminated Core
Max Operating Temperature 105°C
Min Operating Temperature 0°C
Power Rating 40W
Max Power Dissipation 40W
Termination Style Wire Leads, Quick Connect
Max Output Current 1.67A
Power - Max 40VA
Voltage - Primary 347V
Primary Winding(s) Single
Center Tap No
Voltage - Secondary (Full Load) 24V
Dimensions
Height 50.3mm
Height Seated (Max) 50.29mm
Compliance
RoHS Status ROHS3 Compliant
