RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers Class2, Energy Limit 120V, 1.67A, 20VA
PDF
/
Buying Options
Total Price: USD $18.42
Unit Price: USD $18.4184
≥1 USD $18.4184
≥10 USD $16.25184
≥100 USD $13.543112
Inventory: 85
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Box, Chassis Mount, Panel
Mounting Type Chassis Mount
Weight 1.2lbs 544.3g
Technical
Published 2008
Series BD
Size / Dimension 59.18mm Lx59.44mm W
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Quick Connect
ECCN Code EAR99
Type Laminated Core
Max Operating Temperature 105°C
Min Operating Temperature 0°C
HTS Code 8504.31.40.35
Power Rating 20W
Max Power Dissipation 20W
Current Rating 1.67A
Frequency 60Hz
Termination Style Wire Leads, Quick Connect
Approval Agency CSA, UL
Max Output Current 1.67A
Output Current 1.67A
Power - Max 20VA
Voltage - Primary 120V
Primary Winding(s) Single
Center Tap No
Voltage - Secondary (Full Load) 12V
Number of Secondary Winding 1
VA Rating 20 VA
Dimensions
Height 50.3mm
Height Seated (Max) 50.29mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
