269GX image
Favorite
269GX image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description Power Transformers POWER TRANSFORMER
PDF
/
Buying Options
Total Price: USD $62.11
Unit Price: USD $62.1104
≥1 USD $62.1104
≥10 USD $60.04328
≥100 USD $51.761512
Inventory: 15
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Mount Chassis Mount
Mounting Type Chassis Mount
Weight 1.9lbs 861.8g

Technical

Published 2000
Series 269
Size / Dimension 55.63mm Lx66.80mm W
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Wire Leads
ECCN Code EAR99
Type Laminated Core
Additional Feature ADDITIONAL SECONDARY OF 6.3V FOR FILAMENT
HTS Code 8504.31.40.65
Power Rating 48W
Max Power Dissipation 48W
Current Rating 75mA
Termination Style Wire Leads
Approval Agency CSA
Voltage - Isolation 2000Vrms
Max Output Current 2.5A
Current - Output (Max) 75mA 2.5A
Power - Max 48VA
Voltage - Primary 115V
Primary Winding(s) Single
Center Tap Yes
Voltage - Secondary (Full Load) 450V 6.3V
Secondary Winding(s) Dual
VA Rating 48 VA

Dimensions

Height 66.802mm
Height Seated (Max) 66.80mm

Compliance

RoHS Status ROHS3 Compliant
