266V6B
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers DualPrimarySecondary 126VA, 6.3V CT @ 20A
PDF
/
Buying Options
Total Price: USD $88.54
Unit Price: USD $88.5368
≥1 USD $88.5368
≥10 USD $85.58616
≥100 USD $79.684
≥500 USD $73.781488
Inventory: 88
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 96.77mm
Technical
Voltage - Secondary (Full Load) Parallel 3.15V Series 6.3V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 117V 234V
Power - Max 126VA
Current - Output (Max) Parallel 40A Series 20A
Max Output Current 20A
Voltage - Isolation 2000Vrms
Termination Style Wire Leads
Current Rating 20A
Max Power Dissipation 126W
Power Rating 126W
Type Laminated Core
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 79.50mm Lx90.42mm W
Series 266
Published 2008
Physical
Weight 6.4lbs 2.9kg
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 4 Weeks
