266N12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers DualPrimarySecondary 50.4VA, 12.6V CT @4A
PDF
/
Buying Options
Total Price: USD $37.61
Unit Price: USD $37.6112
≥1 USD $37.6112
≥10 USD $36.35632
≥100 USD $31.341288
Inventory: 53
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 66.55mm
Height 66.5mm
Technical
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 117V 234V
Power - Max 50.4VA
Output Current 8A
Current - Output (Max) Parallel 8A Series 4A
Max Output Current 4A
Output Voltage 6.3V
Voltage - Isolation 2000Vrms
Approval Agency CSA, UL
Termination Style Wire Leads
Current Rating 8A
Max Power Dissipation 50.4W
Power Rating 50.4W
Type Laminated Core
ECCN Code EAR99
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 101.60mm Lx56.13mm W
Series 266
Published 2008
Physical
Weight 2.7lbs 1.2kg
Mounting Type Chassis Mount
Mount Chassis Mount, Panel
Supply Chain
Factory Lead Time 4 Weeks
