229D40
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers XFMR 115/230V 40V
PDF
/
Buying Options
Total Price: USD $33.71
Unit Price: USD $33.7128
≥1 USD $33.7128
≥10 USD $29.744
≥100 USD $24.786432
Inventory: 37
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Number of Pins 8
Weight 1.6lbs 725.7g
Technical
Packaging Bulk
Published 2000
Series 229
Size / Dimension 63.50mm Lx79.25mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Type Semi-Toroidal
Max Operating Temperature 130°C
Min Operating Temperature 0°C
Additional Feature PCB MOUNTABLE
Power Rating 48W
Max Power Dissipation 48W
Termination Style PC Pin
Approval Agency cULus
Voltage - Isolation 1750Vrms
Max Output Current 1.2A
Current - Output (Max) Parallel 2.4A Series 1.2A
Power - Max 48VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 20V Series 40V
Number of Secondary Winding 1
Dimensions
Height 35.05mm
Compliance
RoHS Status ROHS3 Compliant
