229B120
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR SEMI-TORO 12VA THRU HOLE
PDF
/
Buying Options
Total Price: USD $16.86
Unit Price: USD $16.8608
≥1 USD $16.8608
≥10 USD $14.87816
≥100 USD $12.39876
Inventory: 92
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 27.18mm
Height 27.178mm
Technical
Number of Secondary Winding 1
Voltage - Secondary (Full Load) Parallel 60V Series 120V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Power - Max 12VA
Current - Output (Max) Parallel 200mA Series 100mA
Max Output Current 100mA
Voltage - Isolation 1750Vrms
Approval Agency cULus
Termination Style PC Pin
Max Power Dissipation 12W
Power Rating 12W
Additional Feature PCB MOUNTABLE
Min Operating Temperature 0°C
Max Operating Temperature 130°C
Type Semi-Toroidal
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 50.80mm Lx63.50mm W
Series 229
Published 2000
Physical
Weight 0.61lb 276.69g
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 12 Weeks
