186D20
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers DualPrimary 115/230V 30VA, 20V CT @1.5A
PDF
/
Buying Options
Total Price: USD $17.97
Unit Price: USD $17.9696
≥1 USD $17.9696
≥10 USD $15.85144
≥100 USD $15.323264
≥500 USD $13.738208
≥1000 USD $13.209768
Inventory: 21
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Weight 1.3lbs 589.7g
Technical
Published 2007
Series 186
Size / Dimension 82.55mm Lx52.20mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
ECCN Code EAR99
Type Laminated Core
Power Rating 30W
Max Power Dissipation 30W
Current Rating 1.5A
Termination Style Solder, Quick Connect
Voltage - Isolation 2000Vrms
Lead Length 6.35mm
Max Output Current 1.5A
Power - Max 30VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap Yes
Voltage - Secondary (Full Load) 20V
Secondary Winding(s) Single
Dimensions
Height 49.02mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
