186B120
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers DualPrimary 115/230V 6VA, 120V CT @0.05A
PDF
/
Buying Options
Total Price: USD $14.12
Unit Price: USD $14.1152
≥1 USD $14.1152
≥10 USD $10.428
≥100 USD $9.625792
≥500 USD $9.304768
≥1000 USD $9.04816
≥3000 USD $8.919821
Inventory: 67
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 34.80mm
Height 34.79mm
Technical
Secondary Winding(s) Single
Voltage - Secondary (Full Load) 120V
Center Tap Yes
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Power - Max 6VA
Max Output Current 50mA
Lead Length 6.35mm
Voltage - Isolation 2000Vrms
Approval Agency CSA, UL
Termination Style Solder, Quick Connect
Current Rating 50mA
Max Power Dissipation 6W
Power Rating 6W
Type Laminated Core
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 60.20mm Lx41.28mm W
Series 186
Published 2008
Physical
Weight 0.43lb 195.04g
Mounting Type Chassis Mount
Mount Chassis Mount, Panel
Supply Chain
Factory Lead Time 4 Weeks
