185F12 image
Favorite
185F12 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description Power Transformers Global/Chassis Mount 130VA/12.6V [email protected]
PDF
/
Buying Options
Total Price: USD $40.75
Unit Price: USD $40.7528
≥1 USD $40.7528
≥10 USD $39.3976
≥100 USD $33.963248
Inventory: 48
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Chassis Mount, Panel
Mounting Type Chassis Mount
Weight 4lbs 1.8kg

Technical

Published 2008
Series 185
Size / Dimension 71.37mm Lx77.98mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
ECCN Code EAR99
Type Laminated Core
Power Rating 130W
Max Power Dissipation 130W
Current Rating 20.6A
Termination Style Solder, Quick Connect
Approval Agency CE, TUV, cULus
Voltage - Isolation 4000Vrms
Output Voltage 6.3V
Max Output Current 10.3A
Current - Output (Max) Parallel 20.6A Series 10.3A
Output Current 20.6A
Power - Max 130VA
Nominal Input Voltage 115V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V

Dimensions

Height 85.6mm
Height Seated (Max) 85.60mm

Compliance

RoHS Status ROHS3 Compliant
