183F24
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers DualPrimary 115/230V 5VA, 24V CT @ .21A
PDF
/
Buying Options
Total Price: USD $13.09
Unit Price: USD $13.0856
≥1 USD $13.0856
≥10 USD $9.6624
≥100 USD $8.383936
≥500 USD $8.027202
Inventory: 89
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 34.93mm
Height 35.05mm
Technical
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Power - Max 5VA
Current - Output (Max) Parallel 420mA Series 210mA
Max Output Current 210mA
Voltage - Isolation 4000Vrms
Termination Style PC Pin
Current Rating 210mA
Max Power Dissipation 5W
Power Rating 5W
Min Operating Temperature 0°C
Max Operating Temperature 155°C
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 41.28mm Lx36.50mm W
Series 183
Published 2008
Physical
Weight 0.37lb 167.83g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
