182Q6 image
Favorite
182Q6 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description Power Transformers Dual Secondary, Open 80VA, 12V CT @ 6.67A
PDF
/
Buying Options
Total Price: USD $214.84
Unit Price: USD $214.842956
≥1 USD $214.842956
≥200 USD $85.724493
≥500 USD $82.859745
≥1000 USD $81.444439
Inventory: 3619
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Mount Chassis Mount, Panel
Mounting Type Chassis Mount
Weight 2.2lbs 997.9g

Technical

Published 2013
Series 182
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
ECCN Code EAR99
Type Toroidal
Power Rating 80W
Max Power Dissipation 80W
Termination Style Wire Leads
Approval Agency CE, CSA, UL
Voltage - Isolation 4000Vrms
Max Output Current 6.67A
Current - Output (Max) Parallel 13.34A Series 6.67A
Power - Max 80VA
Voltage - Primary 117V 234V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 6V Series 12V

Dimensions

Diameter 93.2mm
Height 38.6mm
Height Seated (Max) 30.61mm

Compliance

RoHS Status ROHS3 Compliant
