182M12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers Dual Secondary, Open 80VA, 24V CT @ 3.33A
PDF
/
Buying Options
Total Price: USD $187.99
Unit Price: USD $187.987587
≥1 USD $187.987587
≥200 USD $75.008603
≥500 USD $72.502277
≥1000 USD $71.264212
Inventory: 6704
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Chassis Mount, Panel
Mounting Type Chassis Mount
Weight 2.2lbs 997.9g
Technical
Published 2013
Series 182
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
ECCN Code EAR99
Type Toroidal
Power Rating 80W
Max Power Dissipation 80W
Termination Style Wire Leads
Approval Agency CE, CSA, UL
Voltage - Isolation 4000Vrms
Max Output Current 3.33A
Current - Output (Max) Parallel 6.66A Series 3.33A
Power - Max 80VA
Voltage - Primary 117V 234V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Dimensions
Diameter 93.2mm
Height 38.6mm
Height Seated (Max) 30.61mm
Compliance
RoHS Status ROHS3 Compliant
