166M18 image
Favorite
166M18 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 54VA CHAS MOUNT
PDF
/
Buying Options
Total Price: USD $31.58
Unit Price: USD $31.5832
≥1 USD $31.5832
≥10 USD $27.86432
≥100 USD $26.93504
≥500 USD $24.148608
≥1000 USD $23.219856
Inventory: 81
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Height Seated (Max) 58.67mm
Height 58.7mm

Technical

Number of Secondary Winding 1
Center Tap Yes
Primary Winding(s) Single
Nominal Input Voltage 115V
Power - Max 54VA
Output Current 3A
Max Output Current 3A
Output Voltage 18V
Voltage - Isolation 2000Vrms
Approval Agency CSA, UL
Termination Style Wire Leads
Frequency 60Hz
Current Rating 3A
Max Power Dissipation 54W
Power Rating 54W
Min Operating Temperature 0°C
Max Operating Temperature 130°C
Type Laminated Core
ECCN Code EAR99
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 93.73mm Lx54.10mm W
Series 166
Published 2008
Packaging Bulk

Physical

Weight 2lbs 907.2g
Mounting Type Chassis Mount
Mount Chassis Mount, Panel

Supply Chain

Factory Lead Time 12 Weeks
