166K12 image
Favorite
166K12 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 14.4VA CHAS MNT
PDF
/
Buying Options
Total Price: USD $25.1
Unit Price: USD $25.0976
≥1 USD $25.0976
≥10 USD $22.14432
≥100 USD $18.453688
Inventory: 17
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Mount Chassis Mount
Mounting Type Chassis Mount
Weight 0.9lb 408.23g

Technical

Published 2000
Series 166
Size / Dimension 82.55mm Lx41.40mm W
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Wire Leads
ECCN Code EAR99
Type Laminated Core
Max Operating Temperature 130°C
Min Operating Temperature 0°C
Power Rating 14.4W
Max Power Dissipation 14.4W
Current Rating 1.2A
Termination Style Wire Leads
Approval Agency UL; CSA
Voltage - Isolation 2000Vrms
Output Voltage 12V
Max Output Current 1.2A
Output Current 1.2A
Power - Max 14.4VA
Nominal Input Voltage 115V
Primary Winding(s) Single
Center Tap Yes
Number of Secondary Winding 1

Dimensions

Height 42.9mm
Height Seated (Max) 50.80mm

Compliance

RoHS Status ROHS3 Compliant
