166G80 image
Favorite
166G80 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 40VA CHAS MOUNT
PDF
/
Buying Options
Total Price: USD $35.84
Unit Price: USD $35.8424
≥1 USD $35.8424
≥10 USD $31.62368
≥100 USD $26.35292
Inventory: 31
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Height Seated (Max) 58.67mm
Height 58.674mm

Technical

Number of Secondary Winding 1
Center Tap Yes
Primary Winding(s) Single
Nominal Input Voltage 115V
Power - Max 40VA
Output Current 500mA
Operating Supply Voltage 115V
Max Output Current 500mA
Output Voltage 80V
Voltage - Isolation 2000Vrms
Approval Agency UL; CSA
Termination Style Wire Leads
Frequency 60Hz
Current Rating 500mA
Max Power Dissipation 40W
Power Rating 40W
Min Operating Temperature 0°C
Max Operating Temperature 130°C
Type Laminated Core
ECCN Code EAR99
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 93.73mm Lx47.75mm W
Series 166
Published 2008
Packaging Bulk

Physical

Weight 1.5lbs 680.4g
Mounting Type Chassis Mount
Mount Chassis Mount

Supply Chain

Factory Lead Time 4 Weeks
