166D20
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 2VA CHAS MOUNT
PDF
/
Buying Options
Total Price: USD $26.09
Unit Price: USD $26.092
≥1 USD $26.092
≥10 USD $23.02432
≥100 USD $19.186992
Inventory: 99
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 30.23mm
Technical
Number of Secondary Winding 1
Center Tap Yes
Primary Winding(s) Single
Nominal Input Voltage 115V
Power - Max 2VA
Output Current 100mA
Max Output Current 100mA
Output Voltage 20V
Voltage - Isolation 2000Vrms
Approval Agency UL; CSA
Termination Style Wire Leads
Current Rating 100mA
Max Power Dissipation 2W
Power Rating 2W
Min Operating Temperature 0°C
Max Operating Temperature 130°C
Type Laminated Core
ECCN Code EAR99
Termination Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 52.32mm Lx35.05mm W
Series 166
Published 2000
Physical
Weight 0.3lb 136.08g
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 12 Weeks
