164G120
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers Single Primary 115V 12VA, 120V CT @ .1A
PDF
/
Buying Options
Total Price: USD $10.28
Unit Price: USD $10.2784
≥1 USD $10.2784
≥10 USD $8.228
Inventory: 90
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 38.10mm
Technical
Secondary Winding(s) Dual
Voltage - Secondary (Full Load) Parallel 60V Series 120V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Power - Max 12VA
Current - Output (Max) Parallel 200mA Series 100mA
Max Output Current 100mA
Voltage - Isolation 2500Vrms
Termination Style PC Pin
Max Power Dissipation 12W
Power Rating 12W
Min Operating Temperature 0°C
Max Operating Temperature 130°C
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 47.63mm Lx39.67mm W
Series 164
Published 2000
Physical
Weight 0.7lb 317.51g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 4 Weeks
