162D48
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers DualPrimary 115/230V 1.1VA, 48V CT @.023A
PDF
/
Buying Options
Total Price: USD $7.83
Unit Price: USD $7.832
≥1 USD $7.832
≥10 USD $6.27
Inventory: 42
Minimum: 1
-
+
Technical Details
Technical
Max Operating Temperature 130°C
Min Operating Temperature 0°C
Power Rating 1.1W
Max Power Dissipation 1.1W
Termination Style PC Pin
Voltage - Isolation 2500Vrms
Max Output Current 23mA
Current - Output (Max) Parallel 46mA Series 23mA
Power - Max 1.1VA
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 24V Series 48V
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 34.93mm Lx28.58mm W
Series 162
Published 2000
Dimensions
Height Seated (Max) 33.32mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Weight 0.17lb 77.11g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 4 Weeks
