161H10 image
Favorite
161H10 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description Power Transformers LOW VOLT RECT
PDF
/
Buying Options
Total Price: USD $20.48
Unit Price: USD $20.4776
≥1 USD $20.4776
≥10 USD $18.06464
≥100 USD $15.054072
Inventory: 31
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 35.05mm
Height 35.052mm

Technical

VA Rating 24 VA
Secondary Winding(s) Single, Multiple Taps
Voltage - Secondary (Full Load) Parallel 5V Series 10V
Center Tap No
Primary Winding(s) Single
Voltage - Primary 115V
Power - Max 24VA
Current - Output (Max) Parallel 4.8A Series 2.4A
Max Output Current 2.4A
Voltage - Isolation 2000Vrms
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 24W
Power Rating 24W
HTS Code 8504.31.40.35
Additional Feature PCB MOUNTABLE
Min Operating Temperature 0°C
Max Operating Temperature 130°C
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 41.40mm Lx57.15mm W
Series 161
Published 2000

Physical

Weight 0.82lb 371.95g
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 4 Weeks
