160K12
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
BOBBINS TRANSFORMER - More Details
PDF
/
Buying Options
Total Price: USD $11.33
Unit Price: USD $11.3256
≥1 USD $11.3256
≥10 USD $9.49344
Inventory: 77
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height Seated (Max) 42.93mm
Height 42.926mm
Technical
VA Rating 10 VA
Secondary Winding(s) Single, Multiple Taps
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Power - Max 10VA
Output Current 1.6A
Current - Output (Max) Parallel 1.6A Series 800mA
Operating Supply Voltage 230V
Max Output Current 1.6A
Output Voltage 6.3V
Voltage - Isolation 2000Vrms
Approval Agency UL; CSA
Termination Style PC Pin
Current Rating 1.6A
Max Power Dissipation 10W
Power Rating 10W
HTS Code 8504.31.40.35
Additional Feature PCB MOUNTABLE
Min Operating Temperature 0°C
Max Operating Temperature 130°C
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 49.26mm Lx36.58mm W
Series 160
Published 2000
Physical
Weight 0.64lb 290.3g
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 12 Weeks
