1182R30
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
TRANSFORMER TOROIDAL POWER
PDF
/
Buying Options
Total Price: USD $112.82
Unit Price: USD $112.8248
≥1 USD $112.8248
≥10 USD $109.06808
≥100 USD $101.546016
≥500 USD $94.023952
Inventory: 66
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mounting Type Chassis Mount
Weight 9lbs 4.1kg
Technical
Published 2014
Series 1182
Size / Dimension 139.70mm Dia
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Wire Leads
Type Toroidal
Power Rating 500W
Frequency 60Hz
Termination Style Wire Leads
Voltage - Isolation 4000Vrms
Current - Output (Max) Parallel 16.66A Series 8.33A
Power - Max 500VA
Outside Diameter 139.7 mm
Voltage - Primary 117V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 30V Series 60V
Secondary Current 8.33A
Dimensions
Height 57.15mm
Compliance
RoHS Status ROHS3 Compliant
