1182M15
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
TRANSFORMER TOROIDAL POWER
PDF
/
Buying Options
Total Price: USD $56.42
Unit Price: USD $56.4168
≥1 USD $56.4168
≥10 USD $54.54064
≥100 USD $50.778816
≥500 USD $47.01752
Inventory: 24
Minimum: 1
-
+
Technical Details
Technical
Voltage - Secondary (Full Load) Parallel 15V Series 30V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 117V
Outside Diameter 88.9 mm
Power - Max 80VA
Current - Output (Max) Parallel 5.34A Series 2.67A
Voltage - Isolation 4000Vrms
Termination Style Wire Leads
Frequency 60Hz
Power Rating 80W
Type Toroidal
Termination Wire Leads
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Size / Dimension 88.90mm Dia
Series 1182
Published 2014
Secondary Current 2.67A
Physical
Weight 2.1lbs 952.5g
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 4 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 38.10mm
Height 38.1mm
