6448R-036
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 56VA THRU HOLE
PDF
/
Inventory: 4371
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 63.5mm
Length 76.2mm
Height Seated (Max) 45.97mm
Technical
VA Rating 56 VA
Number of Secondary Winding 2
Output Voltage 2 18V
Voltage - Secondary (Full Load) Parallel 18V Series 36V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 18V
Power - Max 56VA
Current - Output (Max) Parallel 3.12A Series 1.56A
Max Output Current 1.56A
Voltage - Isolation 4000Vrms
Physical Dimension L76.20XB63.50XH45.97 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 56W
Power Rating 56W
Terminal Finish Tin (Sn)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 76.20mm Lx63.50mm W
Series 6448R
Published 2011
Packaging Bulk
Physical
Weight 1.7lbs 771.1g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
