6447R-024
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 30VA THRU HOLE
PDF
/
Inventory: 8288
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 1.2lbs 544.3g
Technical
Packaging Bulk
Published 2011
Series 6447R
Size / Dimension 66.68mm Lx55.55mm W
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin (Sn)
Power Rating 30W
Max Power Dissipation 30W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L66.80XB55.63XH39.62 (mm)
Voltage - Isolation 4000Vrms
Max Output Current 1.25A
Current - Output (Max) Parallel 2.5A Series 1.25A
Power - Max 30VA
Output Voltage 1 12V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Output Voltage 2 12V
Number of Secondary Winding 2
VA Rating 30 VA
Dimensions
Height Seated (Max) 39.67mm
Length 66.8mm
Width 55.63mm
Compliance
RoHS Status ROHS3 Compliant
