6446R-020
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 20VA THRU HOLE
PDF
/
Inventory: 945
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 47.75mm
Length 57.15mm
Height Seated (Max) 36.50mm
Technical
VA Rating 20 VA
Number of Secondary Winding 2
Output Voltage 2 10V
Voltage - Secondary (Full Load) Parallel 10V Series 20V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 10V
Power - Max 20VA
Current - Output (Max) Parallel 2A Series 1A
Max Output Current 1A
Voltage - Isolation 4000Vrms
Physical Dimension L57.15XB47.75XH41.40 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 20W
Power Rating 20W
Terminal Finish Tin (Sn)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 57.15mm Lx47.63mm W
Series 6446R
Published 2011
Packaging Bulk
Physical
Weight 0.9lb 408.23g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
