6443R-012

API Delevan Inc.
RoHS
RoHS RoHS compliant
Package /
Category Transformers / Power Transformers
Description XFRMR LAMINATED 2.5VA THRU HOLE
PDF
/
Inventory: 2555
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 36.58mm
Length 41.4mm
Height Seated (Max) 30.15mm

Technical

VA Rating 2.5 VA
Number of Secondary Winding 2
Output Voltage 2 6.3V
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 6.3V
Power - Max 2.5VA
Current - Output (Max) Parallel 400mA Series 200mA
Max Output Current 200mA
Voltage - Isolation 4000Vrms
Physical Dimension L41.40XB36.58XH28.70 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 2.5W
Power Rating 2.5W
Terminal Finish Tin (Sn)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 34.93mm Lx28.58mm W
Series 6443R
Published 2005
Packaging Bulk

Physical

Weight 0.25lb 113.4g
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 13 Weeks
