6055R-088
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 48VA THRU HOLE
PDF
/
Inventory: 925
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 63.5mm
Length 79.37mm
Height Seated (Max) 36.50mm
Technical
VA Rating 48 VA
Number of Secondary Winding 2
Output Voltage 2 44V
Voltage - Secondary (Full Load) Parallel 44V Series 88V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 44V
Power - Max 48VA
Current - Output (Max) Parallel 1.1A Series 550mA
Max Output Current 1.1A
Voltage - Isolation 1500Vrms
Physical Dimension L79.37XB63.5XH34.92 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 48W
Power Rating 48W
Terminal Finish Tin (Sn)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 47.63mm Lx39.67mm W
Series 6055R
Published 2010
Packaging Bulk
Physical
Weight 1.4lbs 635g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
