6055-012
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 48VA THRU HOLE
PDF
/
Inventory: 2667
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 63.5mm
Length 79.37mm
Height Seated (Max) 36.50mm
Technical
VA Rating 48 VA
Number of Secondary Winding 2
Output Voltage 2 6.3V
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 6.3V
Power - Max 48VA
Current - Output (Max) Parallel 7.6A Series 3.8A
Max Output Current 3.8A
Voltage - Isolation 1500Vrms
Physical Dimension L79.37XB63.5XH34.92 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 48W
Power Rating 48W
Terminal Finish Tin/Lead (Sn/Pb)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e0
Size / Dimension 47.63mm Lx39.67mm W
Series 6055
Published 2010
Packaging Bulk
Physical
Weight 1.4lbs 635g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
