6054R-010
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 24VA THRU HOLE
PDF
/
Inventory: 5522
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.938lb 425.47g
Technical
Packaging Bulk
Published 2010
Series 6054R
Size / Dimension 41.28mm Lx33.32mm W
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin (Sn)
Power Rating 24W
Max Power Dissipation 24W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L73.02XB57.15XH31.74 (mm)
VA Rating 24 VA
Number of Secondary Winding 2
Output Voltage 2 5V
Voltage - Secondary (Full Load) Parallel 5V Series 10V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 5V
Power - Max 24VA
Current - Output (Max) Parallel 4.8A Series 2.4A
Max Output Current 2.4A
Voltage - Isolation 1500Vrms
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 57.15mm
Length 73.02mm
Height Seated (Max) 33.32mm
