6054-016
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 24VA THRU HOLE
PDF
/
Inventory: 6664
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.938lb 425.47g
Technical
Packaging Bulk
Published 2010
Series 6054
Size / Dimension 41.28mm Lx33.32mm W
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin/Lead (Sn/Pb)
Power Rating 24W
Max Power Dissipation 24W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L73.02XB57.15XH31.74 (mm)
Voltage - Isolation 1500Vrms
Max Output Current 1.5A
Current - Output (Max) Parallel 3A Series 1.5A
Power - Max 24VA
Output Voltage 1 8V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 8V Series 16V
Output Voltage 2 8V
Number of Secondary Winding 2
VA Rating 24 VA
Dimensions
Height Seated (Max) 33.32mm
Length 73.02mm
Width 57.15mm
Compliance
RoHS Status Non-RoHS Compliant
