6053R-034
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 12VA THRU HOLE
PDF
/
Inventory: 4176
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.688lb 312.07g
Technical
Packaging Bulk
Published 2010
Series 6053R
Size / Dimension 34.93mm Lx28.58mm W
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin (Sn)
Power Rating 12W
Max Power Dissipation 12W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L63.49XB50.8XH27.05 (mm)
Voltage - Isolation 1500Vrms
Max Output Current 340mA
Current - Output (Max) Parallel 680mA Series 340mA
Power - Max 12VA
Output Voltage 1 17V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 17V Series 34V
Output Voltage 2 17V
Number of Secondary Winding 2
VA Rating 12 VA
Dimensions
Height Seated (Max) 30.15mm
Length 63.49mm
Width 50.8mm
Compliance
RoHS Status ROHS3 Compliant
