6053-012
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 12VA THRU HOLE
PDF
/
Inventory: 2266
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.688lb 312.07g
Technical
Packaging Bulk
Published 2010
Series 6053
Size / Dimension 34.93mm Lx28.58mm W
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin/Lead (Sn/Pb)
Power Rating 12W
Max Power Dissipation 12W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L63.49XB50.8XH27.05 (mm)
Voltage - Isolation 1500Vrms
Max Output Current 1.8A
Current - Output (Max) Parallel 1.8A Series 900mA
Power - Max 12VA
Output Voltage 1 6.3V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 6.3V Series 12.6V
Output Voltage 2 6.3V
Number of Secondary Winding 2
VA Rating 12 VA
Dimensions
Height Seated (Max) 30.15mm
Length 63.49mm
Width 50.8mm
Compliance
RoHS Status Non-RoHS Compliant
