6052R-016
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 6VA THRU HOLE
PDF
/
Inventory: 4139
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.438lb 198.67g
Technical
Packaging Bulk
Published 2010
Series 6052R
Size / Dimension 34.93mm Lx28.58mm W
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin (Sn)
Power Rating 6W
Max Power Dissipation 6W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L47.62XB39.68XH21.59 (mm)
Voltage - Isolation 1500Vrms
Max Output Current 350mA
Current - Output (Max) Parallel 700mA Series 350mA
Power - Max 6VA
Output Voltage 1 8V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 8V Series 16V
Output Voltage 2 8V
Number of Secondary Winding 2
VA Rating 6 VA
Dimensions
Height Seated (Max) 23.80mm
Length 47.62mm
Width 39.68mm
Compliance
RoHS Status ROHS3 Compliant
