6052-024
RoHS
/
Package /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 6VA THRU HOLE
PDF
/
Inventory: 5627
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 39.68mm
Length 47.62mm
Height Seated (Max) 23.80mm
Technical
VA Rating 6 VA
Number of Secondary Winding 2
Output Voltage 2 12V
Voltage - Secondary (Full Load) Parallel 12V Series 24V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 12V
Power - Max 6VA
Current - Output (Max) Parallel 500mA Series 250mA
Max Output Current 250mA
Voltage - Isolation 1500Vrms
Physical Dimension L47.62XB39.68XH21.59 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 6W
Power Rating 6W
Terminal Finish Tin/Lead (Sn/Pb)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
JESD-609 Code e0
Size / Dimension 34.93mm Lx28.58mm W
Series 6052
Published 2010
Packaging Bulk
Physical
Weight 0.438lb 198.67g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
