6051R-040
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 2.5VA THRU HOLE
PDF
/
Inventory: 2424
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Weight 0.313lb 141.97g
Technical
Packaging Bulk
Published 2010
Series 6051R
Size / Dimension 47.60mm Lx39.60mm W
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Type Laminated Core
Terminal Finish Tin (Sn)
Power Rating 2.5W
Max Power Dissipation 2.5W
Termination Style PC Pin
Approval Agency UL; CSA
Operating Temperature (Max) 130°C
Physical Dimension L47.62XB39.68XH16.5 (mm)
Voltage - Isolation 1500Vrms
Max Output Current 62mA
Current - Output (Max) Parallel 124mA Series 62mA
Power - Max 2.5VA
Output Voltage 1 20V
Voltage - Primary 115V 230V
Primary Winding(s) Dual
Center Tap No
Voltage - Secondary (Full Load) Parallel 20V Series 40V
Output Voltage 2 20V
Number of Secondary Winding 2
VA Rating 2.5 VA
Dimensions
Height Seated (Max) 16.50mm
Length 47.62mm
Width 39.68mm
Compliance
RoHS Status ROHS3 Compliant
